Hikvision, DS-9632NI-I8/64TB, 32 Channel 4K NVR 2U 19" Case - 64TB
- Brand:Hikvision
- Product Code:DS-9632NI-I8/64TB
- Availability:Please Call or Email Us to Check Availability
Hikvision, DS-9632NI-I8/64TB, 32 Channel 4K NVR 2U 19" Case - 64TB
Key Features:
- Third-party network cameras supported
- Up to 12 Megapixels resolution recording
- Support 2-ch HDMI, 2-ch VGA, HMDI1 at up to 4K (3840x2160) resolution
- Up to 64 IP cameras can be connected with 320M incoming bandwidth
- Up to 8 SATA interfaces
- Support HDD hot swap with RAID0,1,5,6,10 storage scheme configurable
- Support various VCA detection alarm and VCA search
- Support H.265/H.264/MPEG4 video formats
Technical Specifications:
| Video/Audio Input | |
|---|---|
| IP video input: | 32-ch |
| Two-way audio input: | 1-ch, RCA (2.0 Vp-p, 1kΩ) |
| Network | |
| Incoming bandwidth: | 320Mbps or 200Mbps(when RAID is enabled) |
| Outgoing bandwidth: | 256Mpbs or 200Mbps(when RAID is enabled) |
| Remote connection: | 128 |
| Video/Audio Output | |
| HDMI/VGA output: | 2-ch, resolution: HMDI1:4K (3840 × 2160)/60Hz, 4K (3840 × 2160)/30Hz, 2K (2560 × 1440)/60Hz, 1920 × 1080p/60Hz, 1600 × 1200/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz VGA1: 2K (2560 × 1440)/60Hz, 1920 × 1080p/60Hz, 1600 × 1200/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz HDMI2/VGA2:1920 × 1080p/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz |
| Recording Resolution: | 12MP/8MP/6MP/5MP/4MP/3MP/1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF |
| Audio Output: | 2-ch, RCA (2.0Vp-p, 1KΩ) |
| Synchronous Playback: | 16-ch |
| Decoding | |
| Live view / Playback: | 12MP/8MP/6MP/5MP/4MP/3MP/1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF |
| Capability: | 4-ch@8MP,16-ch@1080P |
| Hard Disk | |
| SATA: | 8 SATA interfaces for 8 HDDs |
| Interface Type: | 1 eSATA interface |
| Capacity: | Up to 6TB capacity for each HDD |
| Disk array | |
| Array type: | RAID0, RAID1, RAID5, RAID10 |
| Number of array: | 4 |
| External Interface | |
| Network Interface: | 2 RJ-45 10/100/1000Mbps self-adaptive Ethernet interfaces |
| Serial Interface: | RS-232, RS-485, Keyboard |
| USB Interface: | Front panel: 2 × USB 2.0 Rear panel: 1 × USB 3.0 |
| Alarm In: | 16-ch |
| Alarm Out: | 4-ch |
| General | |
| Power Supply: | 100 to 240 VAC, 50 to 60 Hz |
| Consumption(without hard disk and POE): | ≤30 W |
| Working Temperature: | -10 ºC ~ +55 ºC (+14 ºF~ + 131 ºF) |
| Working Humidity: | 10 % ~ 90 % |
| Chassis: | 19-inch rack-mounted 2U chassis |
| Dimensions: | 445 × 470 ×90 mm (17.5"× 18.5" × 3.5") |
For more details, please refer with our attached datasheet.
