Ziton, GBX370, I.S. Galvanic Isolator for AS372/FA370
The GBX370 is a galvanic barrier specifically designed to drive sounders and beacons, which are located in intrinsic safe areas. It is recommended to be used in conjunction with the AS372, FA370 or FA370C.
Key Features:
- Output EEx ia IIC
- EMC acc. to NAMUR NE 21
- Up to SIL3 acc. to IEC 61508
- 45 mA Output
Technical Specification:
Input
Voltage : 5 to 35 VDC
Current : 7 mA at 18.5 VDC / 85 mA at 35 VDC
Power loss : 1.3 W
Output
Internal resistor : <= 294 ohm
Open loop voltage : >= 22.8V
Limit : Ie: >=45.3 mA, Ue : 9.1V
Rated current : 45 mA
Ambient temperature : -20°C to +60°C
Mechanical specifications
Protection degree : IP20
Weight : ± 100 g
Dimensions : 20 x 107 x 115 mm
Group, category, type of protection : II (1) G D [EEx ia] IIC (-20°C <= Tamb <= 60°C)
Type of protection [EEx ia]
Explosion group : IIA IIB IIC
External capacitance : 2.9 µF 0.82 µF 0.107 µF
External inductance : 36.02 mH 17.72 mH 4.3 mH
For more details, please refer with our attached datasheet.
