CDVI, VIR-P5 (VIRP5024), Floor Mounted Magnetic Door Holder (24Vdc)

CDVI, VIRP5 (VIRP5024), Floor Mounted Magnetic Door Holder (24Vdc)

A range of door holders from CDVI to provide  the  retention  of  doors  in  the  open  position,  which will be released under fire conditions. Ideal for hotels, hospitals, public buildings etc, the  VIR series operate at 24Vdc - the same operating  voltage as Fire Alarms.

Mounted on the wall or the floor, the magnetic coils  bond to the armatures which are mounted on the  door leaf - this keeps the door in the open position. On receiving a change of state from the fire alarm (or  similar source), the coils will de-energise and  remove  all  magnetism  between  the  main  retainer  body and the armature, allowing the doors to close  in line with fire regulations.

All the VIR door holders are fail-safe to ensure full  compliance, and each model includes a test button to  easily check the operation. All units are CE EN1155  certified. The holding force of 50kg is sufficient to retain even  the heaviest of doors

Key Features:
