C-TEC, BF376, Polarised 24V Relay on a Plate (5A)

C-TEC, BF376, Polarised 24V Relay on a Plate (5A)

C-TEC manufacture a range of durable, reliable and cost-effective fire alarm ancillaries, including:

• The BF376 24V 5A Relay on a Plate

The BF376 is a general purpose, double-pole, polarised 24V 5A relay designed for use in 24V fire alarm systems. Incorporating a red LED which illuminates when the relay is active, it may be connected to a suitable control panel relay output or a standard polarised fire alarm sounder circuit to operate door retaining magnets, rollershutter doors, etc.

Note, if connecting to a sounder circuit, the relay will return to its normal state when the fire condition is cleared or silenced. Always check with the approving authority that the proposed arrangement is acceptable before installation.

Can be mounted on a 25mm flush or surface UK single gang back box.

Specifications:

• Contact configuration: Double pole changeover
• Input coil voltage range: 18 - 30 V d.c.
• Current consumption:typically 30mA @ 24V d.c.
• Contact rating @ 24V d.c: 5A (resistive) 2A (inductive)
• Contact rating @ 240V a.c: 5A (resistive) 2A (inductive)
• Contact material: Silver Nickel
• Dimensions (WxHxD): 86 x 86 x 28mm
• Weight: 101g (packed
