Bell, CS109-31/VR, 31 Way Combined VR Door Entry System

Bell, CS109-31/VR, 31 Way Combined VR Door Entry System

The standard CS109 series meets the needs of most combined applications when security is paramount. It is available from single station system up to any number of telephone stations. However, the keypad feature is available on any of our door entry systems and can be included with vandal resistant VRP or LCP style panels, brass panels, video panels and DPX digital panels. There are ten user access codes and a wide range of programmable functions.

A CS109 series system comprises of:

• 1 x CS109-31 - audio door entry panel, + keypad (31 Button)
• 1 x 212 - 12V AC 1 Amp. power supply
• 31 x 801 - Audio Telephone(S)
• 1 x 203 - Rim Lock Release
• 1 x 51 Speech Unit
• 1 x 340 Power Supply

1) Model 212 (12v AC)

A wall-mounting, double insulated, fused transformer included in basic audio door entry systems up to 10 stations. It has a nominal output of 12v AC @ 1Amp. Compliant with EN60950.

Dimensions: H = 140mm, W = 60mm, D = 53mm

2) 801 - Audio Telephone(S)

The model 801 is Bell Systems original door entry telephone.The 801 telephone continues to be the most popular in the UK market owing to its exceptional reliability and economical price.The model 801 telephone operates from both12v AC or 12v DC and is included in the standard model 900 and VRK audio door entry systems as well as the CS and CSP series of combined keypad and proximity door entry systems.

3) 51 Speech Unit

This compact unit is fitted to the entrance panel on all our current door entry systems except as indicated below. The unit provides two-way speech and has an individual volume control for both microphone and speaker.

• Dimensions H = 97mm W = 58mm D = 24mm
• Can be powered from either 12V AC or 12V DC depending on the model

4) 340C 12V DC 1.5 Amp PSU

A wall-mounting fused 12v DC regulated power supply rated at 1.5 Amp for use on DC door entry systems and our Access Control systems.It can also be used for directly powering failsafe and continuously rated lock releases.Compliant with EN60950.

Dimensions: H = 140mm, W = 60mm, D = 53mm

A 203 Rim Lock Release as a Standard.
