Bell, CSPP20/VR, 20 Button VR Panel and Proximity Reader (Flush)

Bell, CSPP20/VR, 20 Button VR Panel and Proximity Reader (Flush)

It is common for a door entry telephone system to be combined with a proximity access system for the benefit of resident staff or tenants. The CSP series are combined door entry and coded access systems utilising the economic Paxton standalone compact reader. These systems are conveniently packaged with all necessary components to complete an installation including a starter pack of keyfobs. Additional packs of keyfobs can be purchased to the required number - 10,000 keyfob capacity.

A CSP series system comprises of:

• model 801 telephones.
• model CSP door panel with compact proximity reader.
• model 61 speech unit.
• 12V DC power supply.
• model 203 surface lock release.
• starter keyfob pack (includes an 'enrolment' card, a 'fail-open' card and 3 user keyfobs with their shadow cards).

1) Speech Units

Speech Unit Model 61
This compact unit is fitted to the entrance panel on all our current door entry systems(except as indicated below). The unit provides two-way speech and has an individual volume control for both microphone and speaker. This universal product can be powered from either 12V AC or 12V DC depending on the model of telephone used.

Dimensions: H = 97mm, W = 58mm, D = 24mm

2) Power Supplies

Model 340C (12v DC)
A wall-mounting fused 12v DC regulated power supply rated at 1.5 Amp for use on DC door entry systems and our Access Control systems. It can also be used for directly powering failsafe and continuously rated lock releases. Compliant with EN60950.

Dimensions: H = 140mm, W = 60mm, D = 53mm

Model PS4 (12v DC)
A wall-mounting fused 12v DC regulated power supply rated at 4 Amps for use on video entry systems and for powering high current door release mechanisms. Compliant with EN60950.

Dimensions: H = 110mm, W = 235mm, D = 80mm

3) 801 Standard Door Telephone

The model 801 is Bell Systems original door entry telephone.The 801 telephone continues to be the most popular in the UK market owing to its exceptional reliability and economical price.The model 801 telephone operates from both12v AC or 12v DC and is included in the standard model 900 and VRK audio door entry systems as well as the CS and CSP series of combined keypad and proximity door entry systems.

A 203 Surface Lock Release as a Standard.
