ESP (PA16921) PANEL 7 DAY TIME SWITCH WITH BATTERY

ESP (PA16921) PANEL 7 DAY TIME SWITCH WITH BATTERY

  • Brand:ESP
  • Product Code:PA16921
  • Availability:Please Call or Email Us to Check Availability

Please contact sales on 01628 669124 or email sales@hunters-wholesalers.co.uk for a quote on this product


ESP (PA16921) PANEL 7 DAY TIME SWITCH WITH BATTERY

  • Voltage free 16A changeover contact
  • Suitable for Surface, Panel or Din rail mounting
  • 100 hour battery reserve
  • Programming by 1 hour captive segments
  • Manual override with automatic return to program
  • Contact status display

TECHNICAL SPECIFICATIONS:

Power Supply 230V AC, 50/60Hz
Programming 7 Day
Display Analogue
Mounting Optional
Current Rating 16A
Switching Capacity Resistive load 16A 250V Voltage free inductive load (cos = 0.6) 3A 250V Incandescent lamp 1000W 250V Squirrel-cage motor 350W 250V
Reserve 100 hour
Switching Operations 24 per week
Temperature Range -10°C to +50°C
Storage Temperature -10°C to +50°C
Connection by cage terminals, section of conductors 0.5 to 4 mm2
Insulation class 2
Protection IP20
Dimensions 72 x 94.5 x 48.4 mm (Face 72 x 72mm)
Complies with BS EN 60730

For more details on this product range, including part numbers, please refer to the datasheet or contact us on sales@hunters-wholesalers.co.uk for more specific product information and pricing installation and training.
