Fermax, 4840, DIN6 100-240Vac/24Vdc-2A Power Supply
This module prevents the power supply from disrupting the operation of the rest of the signals that circulate through the system, and it will also allow for more power supplies to be connected if required by the system.
Key Features:
- Used to power the different equipment in a Fermax installation.
- Constructed in self-extinguishing VO material.
- Includes a set of covers to protect the connection terminals.
Specifications:
- DIN 6 dimensions: 105x 90 mm x60 mm.
- Input tension: 110-240 Vac.
- Output tension: 24 Vdc.
- Output current: 2A.
- Input protection: PTC and 2,3A fuse.
- Input protection: Electronic limitation for overload and short circuit.
- With two function indicator LEDs:
- ON LED lit: indicates that the power supply is working.
- OVERLOAD LED lit: indicates maximum current exceeded (it will be necessary to reduce the installation load or add additional power supply/supplies).
- ON LED+OVERLOAD blinking: indicates short circuit.
- Power:
- BUS 2 system: 24 VDC.
- DUOX system: 18 VDC.
- Output current depends on the power supply connected. Power supplies of up to 3.5 A.
- BUS 2 system input voltage: 24 VDC.
- DUOX system input voltage: 18 VDC.
