Honeywell (582474) 20W Unidirectional Projection Loudspeaker

Honeywell (582474) 20W Unidirectional Projection Loudspeaker

  • Brand:Honeywell
  • Product Code:582474
  • Availability:Please Call or Email Us to Check Availability

Please contact sales on 01628 669124 or email sales@hunters-wholesalers.co.uk for a quote on this product


Honeywell (582474) 20W Unidirectional Projection Loudspeaker

Honeywell’s voice alarm unidirectional projection loudspeaker complies with BS5839 part 8 and EN54 part 24. Projectors are more directional than cabinet loudspeakers but have better musicality than a horn.

Technical Specifications:

Electrical

  • Max power: 30 W
  • Rated power: 20 W
  • Power taps @ 100V: 20 W / 10 W / 5 W / 2.5 W
  • SPL at 1W/1M ( 100Hz - 10KHz ): 90dB
  • SPL at 10W/1M (100 Hz- 10 KHz ): 101dB
  • Frequency range (-10dB): 150 Hz ~ 20 KHz
  • Rated input voltage: 100 V / 70 V
  • Rated impedance: 500 Ω / 1K Ω / 2K Ω / 4K Ω
  • Connection: Fire-resistant Cable

Mechanical

  • Dimensions (D x L): Φ140 mm x195 mm
  • Colour: White (RAL9003)
  • Material: Aluminum
  • IP Rating: 65

For more details, please refer with our attached datasheet.
