CAME (FROGA) Frog 230V Self-locking Swing Gate Motor - 3.5m Leaf

CAME (FROGA) Frog 230V Self-locking Swing Gate Motor - 3.5m Leaf

Frog is Came’s highly efficient operator that defies time thanks to the materials used in the foundation case and the gearmotor. A smooth, safe movement guaranteed in all working conditions, even the harshest, but which, above all needs no periodic maintenance.

Frog represents the synthesis of CAME’s design philosophy and creativity applied to swing gates. Extremely sturdy and all but invisible, the system in no way detracts from the aesthetics of your entrance. The Frog Residential Underground Swing Gate Operator is ideal for ornamental swing gates. Installed below grade in a waterproof casing, and protected by a steel access plate that is flush with the driveway surface, it provides an invisible solution.

• The invisible solution for the automation of the gate.
• High degree of protection (IP67) from weather agents.
• Automatic re-hooking of the system after a manual release of the gate.
• Can open up to 180° (with the 001FL-180 accessory).
• FROG-AE and FROG-A24E with encoder technology, tested according to the parameters established by law.
• The 24 V versions can also operate during power outages.
• Built-in adjustable gate-leaf stops.

Powerful and fast
The installation is simple and the preparation of the foundation box allows you to automate the window at different times.

Benefits

• For the installer: EN Tested technology for easy installation certification in accordance with the European standards.
• For the user: invisible and safe; installation preserves the aesthetics of the entrance; Self-diagnosis of safety devices, or verify the correct operation of safety devices such as photocells, before automation is put into service.

Special openings
There are levers movement to get special rotations of the doors even up to 180° and to better manage the space.

Designed to withstand all
The case of steel foundation with antioxidant treatment and cataphoresis treatment makes the product highly watertight. The degree of protection against external agents IP67 always make it fully functional even in the worst situations. Also available in stainless steel.

Technical Specifications:

• Protection rating: IP67
• Control panel power supply (V): 230 A.C. 50/60 Hz
• Motor power supply (V): 230 A.C. 50/60 Hz
• Current draw (A): 1,9
• Max Power (W): 200
• Opening time at 90° (s): 18
• Duty cycle (%): 30
• Max torque (Nm): 320
• Operating temperature (°C): -20 ÷ +55

Note: 24V D.C. external operators and control panel is also available.

For more details, please refer with our attached Brochure.
