ESP (RHD8KD4W2TB) 8CH HD 2TB DVR & White Dome Camera CCTV Kit
- Brand:ESP
- Product Code:RHD8KD4W2TB
- Availability:Please Call or Email Us to Check Availability
ESP (RHD8KD4W2TB) 8 Channel HD 2TB DVR & White Dome Camera CCTV Kit
- Complete with 8 Channel DVR, Cameras, Cables & System Power Supplies for 4 Cameras
- HD 2MP Resolution Viewing and Recording
- 4 x 2MP, Day/ Night, Weatherproof Cameras
- Intelligent Function, with Perimeter Intrusion Detection & Line Crossing Detection
- H.265 Video Compression for Efficient Storage
- Pre-Installed Premium Hard Drive
- Remote Monitoring via APP (Android / IOS) or PC
- Playback / Record / Remote View Simultaneously
- Continuous / Scheduled / Motion Record Modes
- USB Backup for Evidence Transfer
- Mouse Driven User Menu
Technical Specifications:
| System | |
| Operating System | LINUX |
| Video & Audio | |
| Video Input | 8 Channel BNC |
| Audio Input | 4 RCA Inputs |
| Audio Output | 1 Channel RCA |
| Display | |
| Video Output | 1 x HDMI, 1 x VGA & 1 x BNC |
| Display Split | 1/4/9/12 |
| Resolution | 1024 x 768, 1280×720, 1280×1024, 1440×900, 1920×1080, 1080 x 1440, 3840 x 2160 |
| Recording | |
| Video/Audio Compression | H.265 |
| Resolution | 1080P @15fps |
| Record Rate (Main Stream) | 4ch 1080P recording |
| Recording Mode | Manual/Motion Detection/Schedule |
| Playback & Backup | |
| Sync Playback | 8ch 1080P playback |
| Backup Mode | USB2.0 devices |
| Network | |
| Ethernet | RJ45 10M/100M |
| Network Functions | HTTP, IPv4/IPv6, TCP/IP, UPNP, RTSP, UDP, SMTP, NTP, DHCP, DNS, PPPOE, DDNS, FTP |
| Network Monitoring | CMS, Android & iPhone apps |
| Storage | |
| Internal HDD | 1 SATA 2TB HDD |
| Auxiliary Interface | |
| USB Interface | 2 |
| General | |
| Power Supply | DC12V/5A |
| Power Consumption | <10W (without hard disk) |
| Operation Condition | 0ºC – +55ºC / 10% – 90% |
| Dimensions | 300mm x 227mm x 53mm |
| Power Supply | DC12V/2A |
| DVR Power Consumption | <10W |
| Operating Temperature | 0°C~+40°C |
| Relative Humidity Resistance | Less than 90%RH |
ALTERNATE PRODUCTS:
| RHD8KD4W | 8CH 1080P HD 1TB 4 WHITE DOME CAMERA KIT |
| RHD8KD4W4TB | 8CH 1080P HD 4TB 4 WHITE DOME CAMERA KIT |
For more details on this product range, including part numbers, please refer to the datasheet below or contact us.
