THEPREMA S360-101 UP WH, PIR Presence Detector(Flush Mount)
- Brand:Timeguard
- Product Code:THEPREMA S360-101 UP WH
- Availability:Please Call or Email Us to Check Availability
THEPREMA S360-101 UP WH, PIR Presence Detector(Flush Mount)
- PIR Presence Detector for ceiling mounting.
- 360° square detection, range up to 64m2 at 2.5m mounting height.
- Choice of fully or semi-automatic (absence detection) operation.
- Timer adjustment – from 10 seconds to 60 minutes.
- LUX adjustment – from 5 to 3000 LUX.
- Total switching: 2300W incandescent/halogen, 1150W fluorescent/low energy plus 70W LED.
- Mixed light measurement suitable for fluorescent, halogen and incandescent lighting types as well as LEDs.
- Pulse function for staircase lighting.
- IP40 weatherproof rating.
- Optional user remote control theSenda S.
- Optional service remote control theSenda P.
SPECIFICATION:
| Operating Voltage | 230V AC |
|---|---|
| 1 or 2 Channel | 1 Channel |
| Controls LED Lighting | Up to 70W |
| 1st Channel Filament/Halogen Loading (W) | 2300 |
| 1st Channel Fluorescent/Low Energy Loading (W) | 1150 |
| Weatherproof Rating | IP40 |
| Detection Range (Max) Metres | 64 |
| Angle of Detection | 360º |
| Light ON Time After Last Detection (Adjustable) | 10 Seconds (Min), 60 Minutes (Max) |
| Permanent ON Facility | (Electronic) |
| Adjustable Light Level Control | Yes |
| EC Directives | Conforms to Latest Directives |
| Overall Dimensions (mm) | Height 77, Width 110, Depth 110 |
