Bell, VRP13-S, 13 Button Vandal Resistant Panel (Surface)

Bell, VRP13-S, 13 Button Vandal Resistant Panel (Surface)

The VRP panels are manufactured from 2.5 mm 316 marine grade stainless steel or optionally in solid brass. They are supplied for flush mounting with a zintec back-box or optionally for surface fitting with a stainless steel cowling. The panel is fixed to its back-box with tamper proof bolts (a special hex bit is supplied).

A single stainless steel vandal resistant push-button (or brass button for brass panel) is provided for each station and optionally for Trades.

These IP68 rated buttons are individually attached by means of a nut on the rear of the panel.

For each push-button a number or letter can be engraved on the panel for permanent identification. The engraving of flat numbers is included in the price but any further engraving, e.g. building names or instructions will incurr a modest surcharge.

Although we generally supply panels to fit standard back boxes, they can be manufactured to custom dimensions; prices for this can be obtained on application.

Since there are many variations with vandal panels an illustrative and dimensioned drawing is provided for approval prior to manufacture.

• 13 Button - Vandal Resistant
• Manufactured from 2.5 mm 316 marine grade stainless steel
• Surface mounting

Custom layouts can include:

• Custom engraving with numbers and text
• Trades facility
• Cut out for CCD camera
• Cut out for Proximity readers with stud fixings
• Keypads for access control

Speech Unit Model 61:
This compact unit is fitted to the entrance panel on all our current door entry systems(except as indicated below). The unit provides two-way speech and has an individual volume control for both microphone and speaker. This universal product can be powered from either 12V AC or 12V DC depending on the model of telephone used.

Dimensions: H = 97mm, W = 58mm, D = 24mm

NOTE: All panels require a model 61 speech unit.
