Videx, C4KVID6SNC/CL, 6 Way 4000 Series Colour Video Kit with Codelock

Videx, C4KVID6SNC/CL, 6 Way 4000 Series Colour Video Kit with Codelock

  • Brand:Videx
  • Product Code:C4KVID6SNC/CL
  • Availability:Please Call or Email Us to Check Availability

Please contact sales on 01628 669124 or email sales@hunters-wholesalers.co.uk for a quote on this product


Videx, C4KVID6SNC/CL, 6 Way 4000 Series Colour Video Kit with Codelock

6 Way 4000 series colour video systems. These systems are based on the 2200 non coax 6 wire video.

The Door panels have "Calling" "Speak", "Busy" and "Door Open" Led's and bright white led lighting for camera. Speakers have adjustable speech controls.

Available in flush or surface mount (/S)Monitors have 3 position call volume adjustment, camera recall, contrast and brightness adjustment. a maximum of 3 monitors can used installed per call button ( or a combination of 3 monitors(3371), audio handsets (3117A) or extension sounders(512D). Requires 3980 mounting plate. Door panel are fitted with codelock.

3371: Is a digital mono videophone based on a 6 Wire BUS, it includes 5 push buttons; a door-open button, an alarm or camera recall (depending on the settings) button and three general purpose service push buttons. The call is an electronic tone with a 3 level volume control which can be adjusted by the user.

Audio Handsets 3117A: These 5 button handset can be used as an intercom system between up to 5 handsets or, with the addition of a door panel and switching call tone generator, as a combined door entry and intercom system. Button include 4 call buttons to other handsets and a lock release button. Plug in handset & cord are also standard.

Extension Sounders 512D: Compatible with the 2 wire BUS and has an 8 way Dip-switch to program the address of the device. Up to 3 units can be addressed with the same number (Ex.: 1 intercom and 2 extension sounders to be operated with the same apartment number). The call tone is different according to the origin of the call (Main entrance call or local door bell).

The codelock has 2 codes, 2 changeover relay outputs and an override input. It can be programmed from 1-99 seconds or latching output. Monitors are also available in silver(/CR) and carbon fibre effect (/CA)

Specifications:

  • Number of entrances - 1 (Expandable to 10)
  • No. Of cores to telephone - 7
  • PSU - 12Vdc, 20Vdc
  • Recommended cable type - CW1308
  • Maximum number of call buttons - 12
  • Lock output - Dry contact relay (C, NO, NC)
  • Videophone model - 3678
  • PSU model - 521, 893N1
  • Amplifier module - 4203
  • Camera module - 4830/C
  • Codelock module - 4800
